Technical data

Nominal power (kW) 8.0
Heating power range (kW) 7.0 – 11.0
Thermal efficiency (%) 76.0
The diameter of the exhaust outlet (mm) 150
Meets ECODESIGN criteria No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 123.0
CO emission (at 13% O 2) ≤ given in% 0.30
Flue gas temperature (℃) 360.0
Max log length (cm) 35
Pollen emission (dust) (mg / Nm 3 ) 88.9
Compliance with the BImSchV 2 standard. No.
Energy efficiency ratio EEI 100.18
The type of glazing is simple
Opening the door to the left
Material of cast iron
Width (cm) 57.80
Height (cm) 63.00
Depth (cm) 49.00
Air intake No
The combustion chamber lining. No.
Ash box Yes
Decorative glass pane No.
ASDP – automatic control of air supply No.
Turbine TURBOFAN Yes
Water panel No.
