Technical data

Nominal power (kW) 8.0
Heating power range (kW) 3.0 – 10.0
Thermal efficiency (%) 83.0
The diameter of the exhaust outlet (mm) 160
Meets ECODESIGN criteria Yes
Intended for recuperation .Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 171.0
CO emission (at 13% O 2) ≤ reported in% 0.09
Flue gas temperature (℃) 180.0
Max log length (cm) 35
Pollen emission (dust) (mg / Nm 3 ) 9.0
Compliance with the BImSchV 2 standard .Yes
EEI Energy Efficiency Ratio 109.30
Minimum required active area of ​​outlet grilles (cm 2 )≥ 700
Minimum required active field of inlet grilles (cm 2 )≥ 500
Type of glazing Side
Opening the door to the right
Material Steel
Width (cm) 78.10
Height (cm) 128.20
Depth (cm) 41.50
Air intake Yes
Combustion chamber lining Yes
Ash box Yes
Decorative glass pane Yes
