Technical data

Nominal power (kW) 17.0
Average power from water (kW) 9.0
Heating power range (kW) 9.0 – 19.5
Thermal efficiency (%) 86.0
Max working pressure (bar) 2.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 293.0
Water capacity (l) 47.0
CO emission (at 13% O 2) ≤ reported in% 0.09
Flue gas temperature (℃) 201.0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 8.0
Compliance with the BImSchV 2 standard. Yes
Energy efficiency ratio EEI 113.20
Opening the door to the left
Material Steel
Width (cm) 91.00
Height (cm) 146.00
Depth (cm) 57.50
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane Yes
Coil Yes
