Technical data

Nominal power (kW) 7.0
Heating power range (kW) 3.0 – 9.0
Thermal efficiency (%) 80.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 274.0
CO emission (at 13% O 2) ≤ reported in% 0.10
Exhaust gas temperature (℃) 245.0
Max log length (cm) 30
Pollen emission (dust) (mg / Nm 3 ) 38.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 105.40
The type of glazing is simple
Opening the door to the left
The material is made of steel, tile
Width (cm) 70.00
Height (cm) 157.00
Depth (cm) 48.80
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane Yes
