Technical data

Nominal power (kW) 11.0
Heating power range (kW) 4.5 – 14.0
Thermal efficiency (%) 80.0
The diameter of the exhaust outlet (mm) 180
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 260.0
CO emission (at 13% O 2) ≤ reported in% 0.10
Exhaust gas temperature (℃) 290.0
Max log length (cm) 40
Pollen emission (dust) (mg / Nm 3 ) 38.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 105.40
Minimum required active area of ​​outlet grilles (cm 2 )≥ 900
Minimum required active field of intake grilles (cm 2 )≥ 700
The type of glazing is simple
Opening the door to the top
Material Steel
Width (cm) 97.70
Height (cm) 132.35
Depth (cm) 54.60
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane No.
