ACR Wychwood

ACR Wychwood

5kW

ACR Stoves

An optional pewter finish handle is available for this stove. When fitted with the optional heat shield, this stove can be installed 100mm away from combustible materials at the rear of the stove and 250mm away from combustible materials at the sides of the stove. Insulated flue pipe must be used to enclose the flue collar when doing this. Please note this is a woodburning stove.

Specifications

Spec Value
Height 525mm
Width 555mm
Depth 347mm
Output Range 5kw nominal (3Kw min / 6.5Kw max)
Efficiency 75.1% gross 82.2% nett
Hearth Requirement Superficial non combustible 12mm hearth required (see Bldg Regs) – below 100 degrees
Weight 90kg
Flue Diameter 125mm
Smoke Exempt? Yes – approved by DEFRA for woodburning in smoke controlled areas
Log Length 35cm
EEI classification for ecolabelling 2018 A+
