Nominal power (kW) 21.0
Heating power range (kW) 11.5 – 29.0
Thermal efficiency (%) 75.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 181.0
CO emission (at 13% O 2) ≤ reported in% 0.22
Exhaust gas temperature (℃) 390.0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 80.6
Compliance with the BImSchV 2 standard. No.
EEI energy efficiency rate 98.88
Minimum required active area of outlet grilles (cm 2 )≥ 1000
Minimum required active field of inlet grilles (cm 2 )≥ 800
The type of glazing is simple
Opening the door to the left
Material of cast iron
Width (cm) 75.00
Height (cm) 90.20
Depth (cm) 44.35
Air intake No
The combustion chamber lining. No.
Ash box Yes
Decorative glass pane No.
