Technical Specifications

Rated output (kW) 7,0
Range of heating power (kW) 5.5 – 9.0
Efficiency (%) 76,0
Exhaust outlet diameter (mm) 130
Complies with Ecodesign criteria Yes
Designed for heat recovery unit No
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 118,0
CO emission (at 13% O 2 ) ≤ given in % 0,09
Flue gas temperature (℃) 250,0
Max log length (cm) 25
Emission of dust (mg/Nm 340,0
Compliance with BImSchV 2 standard Yes
The energy efficiency index EEI 100,18
Glazing type straight
Opening of the doors to the left
Material cast iron, steel
Width (cm) 45,20
Height (cm) 62,80
Depth (cm) 40,06
External air inlet No
The liner of the combustion chamber Yes
Ashpan Yes
Decorative printed glass No
ASDP – automatic control of the air supply No
Water panel No
