Technical data

Nominal power (kW) 8.0
Average power from water (kW) 2.0
Heating power range (kW) 5.4 – 10.5
Thermal efficiency (%) 76.0
The diameter of the exhaust outlet (mm) 130
Meets ECODESIGN criteria No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 120.0
Water capacity (l) 5.0
CO emission (at 13% O 2) ≤ given in% 0.30
Exhaust gas temperature (℃) 290.0
Max log length (cm) 35
Compliance with the BImSchV 2 standard. No.
Energy efficiency ratio EEI 100.18
The type of glazing is simple
Opening the door to the left
Material of production Cast iron, steel
Width (cm) 57.80
Height (cm) 66.80
Depth (cm) 50.00
Air intake No
The combustion chamber lining. No.
Ash box Yes
Decorative glass pane No.
ASDP – automatic control of air supply No.
Turbine TURBOFAN No.
Water panel Yes
