Technical Specifications

Rated output (kW) 16,0
Range of heating power (kW) 8.0 – 22.0
Efficiency (%) 75,0
Exhaust outlet diameter (mm) 200
Complies with Ecodesign criteria No
Designed for heat recovery unit No
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 370,0
CO emission (at 13% O 2 ) ≤ given in % 0,15
Flue gas temperature (℃) 265,0
Max log length (cm) 70
Emission of dust (mg/Nm 3) 42,0
Compliance with BImSchV 2 standard No
The energy efficiency index EEI 98,90
The minimum active field of exhaust grilles (cm 2 )≥ 1000
The minimum active field of inlet grilles (cm 2 )≥ 800
Glazing type tunnel type
Opening of the doors lift up
Material steel
Width (cm) 109,30
Height (cm) 120,00
Depth (cm) 60,50
External air inlet Yes
The liner of the combustion chamber Yes
Ashpan No
Decorative printed glass Yes
