OLIWIA 18 left BS guillotine

///OLIWIA 18 left BS guillotine

OLIWIA 18 left BS guillotine


Kratki Stoves

Technical Specifications

Rated output (kW) 18,0
Range of heating power (kW) 9.0 – 23.0
Efficiency (%) 79,0
Exhaust outlet diameter (mm) 200
Complies with Ecodesign criteria No
Designed for heat recovery unit No
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 263,0
CO emission (at 13% O 2 ) ≤ given in % 0,15
Flue gas temperature (℃) 383,0
Max log length (cm) 50
Emission of dust (mg/Nm 331,0
Compliance with BImSchV 2 standard No
The energy efficiency index EEI 104,10
The minimum active field of exhaust grilles (cm 2 )≥ 1000
The minimum active field of inlet grilles (cm 2 )≥ 800
Glazing type lateral
Opening of the doors lift up, to the right
Material cast iron, steel
Width (cm) 92,60
Height (cm) 119,50
Depth (cm) 58,60
External air inlet No
The liner of the combustion chamber No
Ashpan Yes
Decorative printed glass No
