Technical data

Nominal power (kW) 17.0
Average power from water (kW) 13.0
Heating power range (kW) 8.0 – 23.0
Thermal efficiency (%) 75.0
Max working pressure (bar) 2.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria. No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 209.0
Water capacity (l) 35.0
CO emission (at 13% O 2) ≤ given in% 0.28
Exhaust gas temperature (℃) 305.0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 44.2
Compliance with the BImSchV 2 standard. No.
Energy EfficiencyIndexEEI 98.88
Opening the door to the left
Material of work: steel, cast iron
Width (cm) 81.45
Height (cm) 99.25
Depth (cm) 49.10
Air intake No.
Lining the combustion chamber No.
Ash box Yes
Decorative glass pane No.
Coil Yes
