Technical Specifications

Rated output (kW)7,0
Range of heating power (kW)5.5 – 9.0
Efficiency (%)76,0
Exhaust outlet diameter (mm)150
Complies with Ecodesign criteriaYes
Designed for heat recovery unitNo
Fuel typerecommended seasoned hardwood with moisture ≤20%
Weight (kg)118,0
CO emission (at 13% O 2 ) ≤ given in %0,09
Flue gas temperature (℃)250,0
Max log length (cm)25
Emission of dust (mg/Nm 3)40,0
Compliance with BImSchV 2 standardYes
The energy efficiency index EEI100,18
Glazing typestraight
Opening of the doorsto the left
Materialcast iron, steel
Width (cm)45,20
Height (cm)62,80
Depth (cm)40,60
External air inletNo
The liner of the combustion chamberYes
AshpanYes
Decorative printed glassNo
ASDP – automatic control of the air supplyNo
Turbine TURBOFANNo
Water panelNo

Technical Specifications

Rated output (kW) 7,0
Range of heating power (kW) 5.5 – 9.0
Efficiency (%) 76,0
Exhaust outlet diameter (mm) 150
Complies with Ecodesign criteria Yes
Designed for heat recovery unit No
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 118,0
CO emission (at 13% O 2 ) ≤ given in % 0,09
Flue gas temperature (℃) 250,0
Max log length (cm) 25
Emission of dust (mg/Nm 3) 40,0
Compliance with BImSchV 2 standard Yes
The energy efficiency index EEI 100,18
Glazing type straight
Opening of the doors to the left
Material cast iron, steel
Width (cm) 45,20
Height (cm) 62,80
Depth (cm) 40,60
External air inlet No
The liner of the combustion chamber Yes
Ashpan Yes
Decorative printed glass No
ASDP – automatic control of the air supply No
Turbine TURBOFAN No
Water panel No
