Technical data

Nominal power (kW) 11.0
Heating power range (kW) 4.5 – 14.0
Thermal efficiency (%) 80.0
The diameter of the exhaust outlet (mm) 180
Meets ECODESIGN criteria Yes
Intended for recuperation .Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 161.0
CO emission (at 13% O 2) ≤ reported in% 0.10
Exhaust gas temperature (℃) 290.0
Max log length (cm) 40
Pollen emission (dust) (mg / Nm 3 ) 38.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 105.40
Minimum required active area of ​​outlet grilles (cm 2 )≥ 900
Minimum required active field of intake grilles (cm 2 )≥ 700
Type of glazing Side
Opening the door to the right
Material Steel
Depth (cm) 44.00
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane Yes
