Technical data

Nominal power (kW)16.0
Heating power range (kW)7.5 – 21.0
Thermal efficiency (%)76.0
The diameter of the exhaust outlet (mm)200
Meets ECODESIGN criteria.No.
Intended for recuperation.No.
Fuel typerecommended seasoned hardwood with moisture ≤20%
Weight (kg)183.0
CO emission (at 13% O 2) ≤ given in%0.50
Flue gas temperature (℃)355.0
Max log length (cm)50
Compliance with the BImSchV 2 standard.No.
Energy efficiency ratio EEI100.18
Minimum required active area of ​​outlet grilles (cm 2 )≥1000
Minimum required active field of intake grilles (cm 2 )≥800
Type ofsideglazing
Opening the doorto the left
Material of productionCast iron, steel
Width (cm)72.85
Height (cm)97.35
Depth (cm)49.10
Air intakeNo.
Lining the combustion chamberNo.
Ash boxYes
Decorative glass paneNo.
