Technical data

Nominal power (kW) 12.0
Average power from water (kW) 8.0
Heating power range (kW) 5.0 – 15.0
Thermal efficiency (%) 81.0
Max working pressure (bar) 2.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 160.0
Water capacity (l) 38.0
CO emission (at 13% O 2) ≤ reported in %0.09
Flue gas temperature (℃) 255,0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 33.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 106.70
The type of glazing is simple
Opening the door to the left
Material of work: steel, cast iron
Width (cm) 65.20
Height (cm) 86.90
Depth (cm) 49.60
Air intake No.
Lining the combustion chamber No.
Ash box Yes
Decorative glass pane No.
Coil Yes
