Technical data

Nominal power (kW) 13.0
Average power from water (kW) 11.0
Heating power range (kW) 7.0 – 17.0
Thermal efficiency (%) 71.0
Max working pressure (bar) 2.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria. No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 218.0
Water capacity (l) 17.0
CO emission (at 13% O 2) ≤ given in% 0.31
Flue gas temperature (℃) 322.0
Max log length (cm) 45
Pollen emission (dust) (mg / Nm 3 ) 116.0
Compliance with the BImSchV 2 standard. No.
Energy Efficiency Index EEI 93.66
The type of glazing is simple
Opening the door up
Material of work: steel, cast iron
Width (cm) 90.40
Height (cm) 123.40
Depth (cm) 47.40
Air intake No.
Lining the combustion chamber No.
Ash box Yes
Decorative glass pane Yes
Coil Yes
