LUCY 12 tunnel

LUCY 12 tunnel

12kW

Kratki Stoves

Technical data

Nominal power (kW) 12.0
Heating power range (kW) 5.0 – 15.0
Thermal efficiency (%) 80.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 165.0
CO emission (at 13% O 2) ≤ reported in% 0.10
Flue gas temperature (℃) 270.0
Max log length (cm) 35
Pollen emission (dust) (mg / Nm 3 ) 15.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 105.40
Minimum required active area of ​​outlet grilles (cm 2 )≥ 900
Minimum required active field of intake grilles (cm 2 )≥ 700
A type of glazing Tunnel
Opening the door to the left
Material Steel
Width (cm) 65.40
Height (cm) 128.70
Depth (cm) 42.00
Air intake Yes
Combustion chamber lining Yes
Ash box Yes
Decorative glass pane Yes
