MBA 17 left BS guillotine bent glass

///MBA 17 left BS guillotine bent glass

MBA 17 left BS guillotine bent glass

17kW

Kratki Stoves

Technical data

Nominal power (kW) 17.0
Heating power range (kW) 8.0 – 21.0
Thermal efficiency (%) 80.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 309.0
CO emission (at 13% O 2) ≤ reported in% 0.09
Flue gas temperature (℃) 250.0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 35.0
Compliance with the BImSchV 2 standard. Yes
Energy EfficiencyIndexEEI 105.40
Minimum required active area of ​​outlet grilles (cm 2 )≥ 1000
Minimum required active field of inlet grilles (cm 2 )≥ 800
Opening the door up, right
Material Steel
Width (cm) 96.70
Height (cm) 150.00
Depth (cm) 59.10
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane Yes
