MBM 10 right BS guillotine bent glass

///MBM 10 right BS guillotine bent glass

MBM 10 right BS guillotine bent glass

10kW

Kratki Stoves

Technical data

Nominal power (kW) 10.0
Heating power range (kW) 4.5 – 12.5
Thermal efficiency (%) 81.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria Yes
Intended for recuperation. Yes
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 244.0
CO emission (at 13% O 2) ≤ reported in% 0.10
Exhaust gas temperature (℃) 235.0
Max log length (cm) 50
Pollen emission (dust) (mg / Nm 3 ) 28.0
Compliance with the BImSchV 2 standard. Yes
Energy efficiency ratio EEI 106.71
Minimum required active area of ​​outlet grilles (cm 2 )≥ 700
Minimum required active field of inlet grilles (cm 2 )≥ 500
Type of glazing Side
Opening the door up, to the left
Material Steel
Width (cm) 83.70
Height (cm) 126.90
Depth (cm) 54.60
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane Yes
