Technical data

Nominal power (kW) 24.0
Average power from water (kW) 12.0
Heating power range (kW) 11.0 – 30.0
Thermal efficiency (%) 78.0
Max working pressure (bar) 2.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 227.0
Water capacity (l) 52.0
CO emission (at 13% O 2) ≤ given in% 0.20
Flue gas temperature (℃) 305.0
Max log length (cm) 70
Pollen emission (dust) (mg / Nm 3 ) 53.2
Compliance with the BImSchV 2 standard. No.
Energy Efficiency Index EEI 102.79
The type of glazing is simple
Opening the door to the left
Material Steel
Width (cm) 113.20
Height (cm) 103.40
Depth (cm) 48.80
Air intake Yes
Combustion chamber lining Yes
Ash box No.
Decorative glass pane No.
Coil Yes
