Technical data

Nominal power (kW) 16.0
Heating power range (kW) 7.5 – 21.0
Thermal efficiency (%) 76.0
The diameter of the exhaust outlet (mm) 200
Meets ECODESIGN criteria. No.
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg)182.0
CO emission (at 13% O 2) ≤ given in%0.50
Flue gas temperature (℃)355.0
Max log length (cm)50
Compliance with the BImSchV 2 standard.No.
Energy efficiency ratio EEI100.18
Minimum required active area of ​​outlet grilles (cm 2 )≥1000
Minimum required active field of intake grilles (cm 2 )≥800
Opening the door to the left
Material of production Cast iron, steel
Width (cm) 73.70
Height (cm) 97.30
Depth (cm) 49.10
Air intake No.
Lining the combustion chamber No.
Ash box Yes
Decorative glass pane Yes
