Technical data

Nominal power (kW) 10.0
Heating power range (kW) 5.5 – 13.5
Thermal efficiency (%) 75.0
The diameter of the exhaust outlet (mm) 130
Meets ECODESIGN criteria Yes
Intended for recuperation. No.
Fuel type recommended seasoned hardwood with moisture ≤20%
Weight (kg) 166.0
CO emission (at 13% O 2) ≤ reported in% 0.15
Exhaust gas temperature (℃) 290.0
Max log length (cm) 35
Pollen emission (dust) (mg / Nm 3 ) 14.0
Compliance with the BImSchV 2 standard. No.
Energy EfficiencyIndexEEI 98.90
The type of glazing is simple
Opening the door to the left
Material of cast iron
Width (cm) 76.60
Height (cm) 66.00
Depth (cm) 54.60
Air intake No
The combustion chamber lining. No.
Ash box Yes
Decorative glass pane No.
ASDP – automatic control of air supply Yes
Turbine TURBOFAN No.
Water panel No.
